| ARY356A-72G | ARY366A-72G |
|---|---|
| Rack Option w/o Rack 1 A3500 Controller 2 D1000 Arrays 8 9.1GB Disks 7200 RPM |
Rack Option w/o Rack 1 A3500 Controller 2 D1000 Arrays 8 9.1GB Disks 10000 RPM |
| CODE | PART # | DESCRIPTION |
|---|---|---|
| 1 | 540-3760 | D1000 12-Drive Chassis with Rackmount Tray |
| NS | 300-1340 | 360 Watt Power Supply |
| NS | 370-3290 | Empty 1.0" Disk Drive Slot Filler |
| NS | 375-0008 | Differential SCSI Controller Board |
| NS | 501-4440 | 12-Slot SCSI Disk Backplane |
| NS | 540-3323 | Fan Tray |
| NS - - - - - |
540-3720 370-3404 370-3413 370-3595 390-0004 540-3024 |
9.1GB 7200 RPM Disk Drive Assembly/FRU 9.1GB Disk Drive, IBM DDRS-391309.1GB Disk Drive, Fujitsu MAB3091SC9.1GB Disk Drive, Seagate ST39173WC9.1GB Disk Drive, Fujitsu MAE3091LC1.0" Spud Bracket |
| NS - - - |
540-3966 370-3649 390-0005 390-0009 |
9.1GB 10000 RPM Disk Drive Assembly/FRU9.1GB Disk Drive, Seagate ST39102LC9.1GB Disk Drive, Fujitsu MAG3091LC9.1GB Disk Drive, Seagate ST39103LC |
| 2 2 NS NS NS NS NS |
380-0083 370-2431 370-2436 370-2432 540-3083 370-2434 370-2433 |
A3000/A3500 SCSI Assembly for the A3500 Chassis with Backplane FRU Power SupplyPower Supply Fan AssemblyA3500 Differential SCSI Array ControllerBattery AssemblyDifferential SCSI Array Controller Fan Assembly |
| NS | 150-1890 | Differential Terminator, HD68 |
| NS | 530-1883 | External SCSI Cable, HD68 to HD68, 20 cm |
| NS | 530-1884 | External SCSI Cable, HD68 to HD68, 80 cm |
| NS | 530-1885 | External SCSI Cable, HD68 to HD68, 2M |
| NS | 530-1886 | External SCSI Cable, HD68 to HD68, 12M |
| 805-2624 805-4980 |
A1000/D1000 Installation/Operation/Service Manual StorEdge A3000 Controller Module Guide Manual |
