Seagate ST1480N (424MB)

3 1/2" 4400 RPM Single Ended SCSI

Sun-4/15/30/50/75 / SS10
Option 540

370-1392 540-2165 595-2965
3 1/4" Height FRU SS10 Assembly X540A Assembly

Power

0.8 Amps @ +5Vdc
0.9 Amps @ +12Vdc
14.8 Watts Operating Maximum

References

  1. Desktop Storage Pack Service Manual, 800-4895-10.Internet Link
  2. Installing Drives in a SPARCstation 2, 800-6398-10.Internet Link
